PUF Insulated Co2 Tanks

PUF Insulated Co2 Tanks
PUF Insulated Co2 Tanks
Product Code : 02
Product Description

PUF Insulated CO2 Tanks are widely used in industries for chemical storage purpose. This type of tank is suitable for both above the ground and underground storage. It can store varied liquids and gases under high pressure with complete safety from temperature change. Available in horizontal as well as vertical arrangement, the tanks are uniformly insulated with PUF (polyurethane foam).

Features :

  • Sturdy design
  • Uniform PUF insulation
  • PUF insulation protects the tank from any change in temperature
  • Horizontal and vertical arrangement
  • Suitable for underground storage purpose
  • Can store liquids and gases under high pressure

Specifications :

Capacity

1 MT lo 300 MT

Liquid level gauge

load cell

Pressure gauge

0 to 350 psig (0 to 28Kg/cm2g) with 6" (152.4 mm) dial

Piping

Schedule 40/80 seamless pipe, 3000 lb forged steel fittings, ball type valves

Insulation

6" (150 mm) polyurethane

Outer jacket

(1.0mm) pre-finished aluminum

Vaporizers

OPTIONAL - water heated vapouriser - capacities to 500 lbs/hr (227 kg/h)

Safeties

IS-2825 with SMPV rules approved direct spring loaded or pilot operated, sized for unconfined outdoor installation

Electrical characteristics

included in local panel

Pressure vessel

ASME/European Standard/IS-2825 coded for maximum working pressure of 300 psig (24 barg)

Applications :

  • Refrigeration unit
  • Bottling plant
  • Dry ice making plant
