Industrial Source Based Co2 Recovery Plant

Industrial Source Based Co2 Recovery Plant
Industrial Source Based Co2 Recovery Plant
Product Code : 03
Product Description

Industrial Source Based CO2 Recovery Plant operates at ambient conditions. One of the main advantages with this recovery plant is that it requires no external heating to prevent hydrate formation. This CO2 recovery plant is used extensively in industry to remove heavy components such as C3+ from fuel gas.

Features :

  • Temperature and pressure indication of key process variables
  • Fully automatic operation
  • Touch screen operator interface
  • Water flow indicator for safety
  • Stainless steel construction
  • Valves easily accessible for routine inspection & maintenance
  • Data logging
  • Allow for auto switchover of towers and operation of hot air regeneration equipment

Specification :

Ashirwad Carbonics (India) Private Limited, Ghaziabad (India)

Utility requirement for different capacities CO2 Recovery Plant

Plant Capacity

Power

Make Up Water

Liquid CO2
Storage Capacity

Cooling Water

Kg/Hr.

KW

HP

M3/Hr.

Gal/Min

In Metric Ton

M3/Hr

Gal/Min

100

33.5

44.9

0.4

1.76

15

7

30.8

250

83.7

112.3

1

4.4

25

17.5

77

500

167.5

22.1 6

2

8.8

50

30

132.1

750

251.2

336.9

5.9

13.2

100

45

198.2

1000

334.9

449.2

7.9

17.6

110

60

264.2

1500

502.4

673.8

6

26.5

150

90

396.3

2000

669.9

898.4

8

35.3

200

120

538.4

Larger Capacities are available on request as per customer requirement.

Production Process :

  • Fermenters produce raw gas that is fed into the system of foam trap for removal of foam
  • Booster blower is used to push the gas into the series of scrubbing systems passing through pre water scrubber, KMNO4 scrubber with dosing facilities
  • In this, the CO2 gas is washed properly using water
  • After this, the raw gas is buffered in a vessel
  • From there, it enters into the two stage CO2 compressor for compression up to a desired pressure
  • The raw gas is fed into the dual tower activated carbon filter in which its odor is removed completely
  • The raw gas is passed through the high pressure precooler into the dual tower CO2 dryer and then into liquefaction system and nox removal tower
  • At the end, the liquid goes directly to the storage tank where the gas stores for a particular period of time
